Product Description
| Feature | Specification |
|---|---|
| Model | IPC3532LB‑ADZK‑H |
| Camera Type | 2MP Fixed IR Vandal-Proof Dome |
| Sensor | 1/2.7″ CMOS, Progressive Scan |
| Resolution & Frame Rate | 2MP (1920 × 1080) @ 30/25 fps; 720P (1280 × 720) @ 30/25 fps |
| Lens | Motorized Varifocal 2.8–12mm, F1.6 |
| Field of View (H × V × D) | 103.6°–33.4° × 54.8°–18.7° × 107.9°–37.8° |
| Minimum Illumination | 0.003 lux (color, F1.6, AGC ON); 0 lux with IR on |
| IR Range | Smart IR, up to 40 meters (131 ft) |
| Day/Night Mode | IR-cut filter with auto switch (ICR) |
| Wide Dynamic Range (WDR) | 120 dB True WDR |
| Noise Reduction | 2D/3D Digital Noise Reduction |
| Smart Features | Motion detection, intrusion detection, line crossing, tampering alarm, audio detection |
| Audio | Built-in microphone |
| Storage | MicroSD card support up to 256 GB |
| Network Interface | 10/100 Mbps Ethernet (RJ45) |
| Protocols Supported | ONVIF (Profile S, Profile G, Profile T), API, SDK |
| Power Supply | 12 V DC ±25% or PoE (IEEE 802.3af) |
| Power Consumption | Max 8.0 W |
| Ingress Protection | IP67 (dust and waterproof) |
| Vandal Resistance | IK10 (impact resistant) |
| Operating Temperature | –30°C to +60°C |
| Humidity | ≤ 95% RH (non-condensing) |
| Surge Protection | 6 kV |
| Dimensions (Ø × H) | Ø128 mm × 100 mm |
| Weight | 0.66 kg |
