Product Description
|
Specifications
|
||
|---|---|---|
| Model | OAP1200 | |
| Wireless Standards | IEEE 802.11 a/b/g/n/ac (Wave 2) | |
| Frequency Bands | Dual-band: 2.4 GHz and 5 GHz | |
| Maximum Data Rate | 2.4 GHz: up to 300 Mbps5 GHz: up to 867 MbpsTotal: up to 1167 Mbps | |
| Channel Bandwidth | 20 MHz / 40 MHz / 80 MHz | |
| Antenna | 2 × 4 dBi external omni-directional antennas | |
| Ethernet Port | 1 × Gigabit Ethernet (10/100/1000 Mbps) with PoE support | |
| Power Supply / PoE Support | IEEE 802.3af or 24V 0.5A passive PoE | |
| Maximum Power Consumption | Approximately 11.5 W | |
| Ingress Protection Rating | IP65 (dust-tight and protected against water jets) | |
| Mounting Options | Wall mount or pole mount | |
| Coverage Radius | Up to approximately 200 meters under ideal conditions | |
| Maximum Clients Supported | Up to 256 clients | |
| SSID / VLAN / Advanced Features | Supports up to 12 SSIDs (8 on 2.4 GHz, 4 on 5 GHz), VLAN tagging, WPA3, MU-MIMO, OFDMA, Beamforming, 802.11k/v/r fast roaming | |
| Operating Temperature | –30°C to 50°C | |
| Storage Temperature | –30°C to 70°C | |
| Management Interface | Web-based management, CloudFi app control | |
