Product Description
|
Specifications
|
||
|---|---|---|
| Wi-Fi Standard | IEEE 802.11ac/a/n (Wi-Fi 5 Wave 2) – Dual-band (2.4 GHz + 5 GHz) | |
| Maximum Wireless Speed | 2.4 GHz: Up to 300 Mbps; 5 GHz: Up to 867 Mbps | |
| Total Combined Speed | Up to 1,167 Mbps | |
| Coverage (3 nodes) | Up to 6,000 sq.ft (~557 m²) under optimal conditions | |
| Device Capacity | Supports up to 90 connected devices simultaneously | |
| Ethernet Ports | 2 × Gigabit Ethernet ports per node (WAN + LAN on primary node; LAN on secondary nodes) | |
| Mesh Technology | IEEE 802.11s Mesh Standard | |
| Wireless Features | MU-MIMO, Beamforming, Smart QoS, AP Steering, Band Steering | |
| Security & Software | WPA2-PSK, Parental Controls, Guest Network, VPN pass-through, TR069, IPv6 support | |
| Physical Dimensions | 100 × 100 × 100 mm (3.94 × 3.94 × 3.94 in) per node | |
| Operating Conditions | Temperature: 0 °C to 40 °C; Humidity: 10%–90% RH (non-condensing) | |
| Power Supply | Input: 100–240V AC, 50/60Hz; Output: 12V DC, 1A | |
