Product Description
| Specifications | ||
|---|---|---|
| Product Name | Synology FX2421 24-Bay FlashExpansion Unit | |
| Type | Rackmount Expansion Unit (2U Form Factor) | |
| Drive Bays | 24 x 2.5″ SAS/SATA HDD/SSD (hot-swappable) | |
| Compatible Devices | Synology FlashStation models: FS6400, FS3600, FS3400 | |
| Interface | 1 x Mini-SAS HD Expansion Port (SAS IN), 1 x Mini-SAS HD Expansion Port (SAS OUT) | |
| Maximum Raw Capacity | Up to 92.16 TB (24 x 3.84 TB drives; actual capacity depends on RAID configuration) | |
| Power Supply | 500W Redundant Power Supply Units | |
| Cooling System | 4 x 80mm Replaceable System Fans | |
| Noise Level | 57 dB(A) (measured under specific conditions) | |
| Dimensions (HxWxD) | 88 mm x 430.5 mm x 692 mm (without server ears); 88 mm x 482 mm x 724 mm (with server ears) | |
| Weight | 14.5 kg (without drives) | |
| Operating Temperature | 0°C to 35°C | |
| Storage Temperature | -20°C to 60°C | |
| Relative Humidity | 5% to 95% RH (non-condensing) | |
| Warranty | 5 years (limited) | |
| Included Accessories | 2 x AC Power Cords, 1 x Mini-SAS HD Expansion Cable, Accessory Pack, Quick Installation Guide | |
| Recommended Rack Kit | RKS-02 (sold separately) | |
| Supported Disk Types | Synology SAT5200 (2.5″ SATA SSD), SAS and SATA 2.5″ SSDs/HDDs | |
| Certifications | UL, FCC, CE, EAC, VCCI, RCM, KC | |
