Product Description
Specifications
|
||
---|---|---|
Model | DX1222 | |
Type | 12-Bay Desktop NAS Expansion Unit | |
Compatibility | Synology DiskStation models: DS3622xs+, DS2422+ | |
Drive Bays | 12 (Hot-swappable) | |
Supported Drives | 3.5″ SATA HDD, 2.5″ SATA HDD, 2.5″ SATA SSD | |
Maximum Capacity | Up to 192 TB (12 x 16 TB drives) | |
RAID Support | Managed via Synology DSM (RAID 0, 1, 5, 6, 10, SHR, etc.) | |
Expansion Port | 1 x Mini-SAS HD | |
Power Supply | 550 W internal PSU | |
Power Consumption | 57.71 W (Access), 16.25 W (HDD Hibernation) | |
Operating Temperature | 0°C to 40°C | |
Storage Temperature | -20°C to 60°C | |
Humidity | 5% to 95% RH | |
Noise Level | 24.6 dB(A) | |
Dimensions (H x W x D) | 270 mm x 300 mm x 340 mm | |
Weight | 9.02 kg | |
Warranty | 5 years | |
Certifications | UL, FCC, CE, BSMI, UKCA, EAC, VCCI, RCM, KC, BIS | |
Included Accessories | Power cord, Mini-SAS HD cable, accessory pack | |
Recommended Drives | Synology HAT5300 (HDD) and SAT5200 (SSD) series | |
Notes | Best performance achieved when volumes are created within the same NAS or expansion unit. DSM 7.0.1-42218 or later required. |
