Product Description
| Feature | Specification |
|---|---|
| Model Code | MZ-VAP4T0BW |
| Series | 9100 PRO |
| Capacity | 4TB |
| Form Factor | M.2 2280 |
| Interface | PCIe Gen 5.0 x4, NVMe 2.0 |
| NAND Flash | Samsung V-NAND TLC (236-layer) |
| Controller | Samsung Presto (5nm) |
| Cache Memory | 4GB LPDDR4X SDRAM |
| Sequential Read Speed | Up to 14,800 MB/s |
| Sequential Write Speed | Up to 13,400 MB/s |
| Random Read (QD32) | Up to 2,200,000 IOPS |
| Random Write (QD32) | Up to 2,600,000 IOPS |
| Encryption Support | AES 256-bit, TCG/Opal v2.0, IEEE1667 |
| TRIM Support | Yes |
| S.M.A.R.T Support | Yes |
| Garbage Collection | Automatic |
| Device Sleep Mode | Supported |
| Power Consumption (Active) | Read: Avg. 7.6W / Write: Avg. 7.2W |
| Power Consumption (Idle) | Max 4.0 mW |
| Power Consumption (Sleep) | Max 3.3 mW |
| Operating Temperature | 0°C to 70°C |
| Shock Resistance | 1,500 G & 0.5 ms |
| MTBF | 1.5 Million Hours |
| Endurance (TBW) | 2,400 TBW |
| Dimensions (W x H x D) | 80.15 x 22.15 x 2.38 mm |
| Weight | Max 9.0g |
| Software Support | Samsung Magician, Data Migration Software |
| Warranty | 5-Year Limited Warranty |
