Product Description
|
Specifications
|
||
|---|---|---|
| Graphics Card Name | NVIDIA RTX 5000 Ada 32GB | |
| Part Number / SKU | 490‑BKJX / 8D6B6AA | |
| GPU Architecture | NVIDIA Ada Lovelace (Professional Ada Generation) | |
| CUDA Cores | 8,192 | |
| Tensor Cores | Advanced (Fourth‑generation) | |
| RT Cores | Advanced (Third‑generation) | |
| Graphics Memory | 32 GB GDDR6 with ECC | |
| Memory Interface | 256‑bit | |
| Memory Bandwidth | ~672 GB/s | |
| Peak FP32 Performance | ~42–45 TFLOPS (approximate) | |
| Bus Interface | PCI Express 4.0 x16 | |
| Display Outputs | 4 × DisplayPort 1.4a | |
| Max Simultaneous Displays | Up to 4 | |
| Maximum Resolution (per display) | Up to 7680 × 4320 @ 60 Hz | |
| Power Consumption (TDP) | ~230 W (typical) | |
| Cooling | Active dual‑fan or blower‑style heatsink | |
| Form Factor | Dual‑slot professional design | |
| APIs Supported | DirectX 12 Ultimate, OpenGL, Vulkan, CUDA | |
| HDR / Display Features | HDCP support, DisplayPort audio | |
| VR‑Ready | Yes | |
| Typical Use Cases | Professional workstations, CAD, 3D modeling and rendering, simulation, AI/compute workloads | |
| Warranty | Typically 3 Years | |
