Product Description
|
Specifications
|
||
|---|---|---|
| Graphics Card Name | NVIDIA RTX A5000 24GB | |
| Part Number / SKU | 20X23AA | |
| GPU Architecture | NVIDIA Ampere | |
| CUDA Cores | 8,192 | |
| Tensor Cores | 256 (Third-generation) | |
| RT Cores | 64 (Second-generation) | |
| Graphics Memory | 24 GB GDDR6 with ECC | |
| Memory Interface | 384‑bit | |
| Memory Bandwidth | ~768 GB/s | |
| Peak FP32 Performance | ~27.8 TFLOPS | |
| Bus Interface | PCI Express 4.0 x16 | |
| Display Outputs | 4 × DisplayPort 1.4a | |
| Maximum Displays Supported | Up to 4 simultaneously | |
| Maximum Resolution (per display) | Up to 7680 × 4320 @ 60 Hz | |
| Power Connector | 1 × 8‑pin PCIe | |
| Power Consumption (TDP) | ~230 W | |
| Cooling | Active blower‑style fan | |
| Form Factor | Dual‑slot, full-height professional design | |
| APIs Supported | DirectX 12 Ultimate, OpenGL 4.6, Vulkan 1.2, CUDA | |
| HDR / Display Features | HDCP 2.2, DisplayPort audio | |
| VR‑Ready | Yes | |
| Typical Use Cases | Professional graphics workstations, CAD, 3D modeling, simulation, rendering | |
| Warranty | Typically 3 Years | |
