Product Description
| Specifications | ||
|---|---|---|
| Model | Huawei S310-8T4S | |
| Ports | 8 x GE RJ45 (10/100/1000 Mbps), 4 x GE SFP | |
| Switching Capacity | 32 Gbps | |
| Forwarding Performance | 24 Mpps (million packets per second) | |
| Power Supply | AC Power Supply | |
| PoE Support | No | |
| Layer Support | Layer 2 and basic Layer 3 features | |
| MAC Address Table | 16K entries | |
| VLAN Support | 4K VLANs | |
| QoS | 8 hardware queues per port, traffic classification & priority | |
| Security Features | 802.1x, DHCP snooping, ARP inspection, MAC filtering | |
| Management | Web UI, CLI, SNMP, Telnet, SSH | |
| Installation | Rack or desktop mountable | |
| Dimensions (W x D x H) | Approx. 250 mm × 180 mm × 43.6 mm | |
| Weight | Approx. 1.8 kg | |
| Operating Temperature | 0°C to 50°C | |
| Humidity | 5%–95% RH (non-condensing) | |
| Certifications | CE, FCC, RoHS | |
| Typical Applications | Small business networks, fiber uplinks, access layer switching | |
