Product Description
Specifications
|
||
---|---|---|
Model | S-SFP-GE-LH40-SM1550 (Huawei Part No. 02317347) | |
Product Type | Optical Transceiver Module | |
Form Factor | eSFP (enhanced Small Form-factor Pluggable) | |
Data Rate | 1.25 Gbps (Gigabit Ethernet) | |
Transmission Distance | Up to 40 kilometers (1550 nm, single-mode fiber) | |
Wavelength | 1550 nm (single-mode) | |
Fiber Type | Single-mode Fiber (SMF) | |
Connector Type | LC Duplex | |
Interface Standard | 1000BASE-EX (non-standard) | |
Transmitter Type | DFB (Distributed Feedback) Laser | |
Receiver Type | PIN Photodiode | |
Digital Diagnostic Monitoring (DDM) | Supported (real-time monitoring of optical parameters) | |
Power Consumption | < 1W (typical) | |
Operating Temperature | 0°C to 70°C (commercial grade) | |
Compliance | RoHS Compliant, CE, IEC 60825-1 Class 1 Laser Safety | |
Use Case | Long-distance 1G Ethernet over single-mode fiber |
