Huawei QSFP-100G-SR4-ISP 100GBase-SR4 Optical Transceiver,QSFP28,100G,Multi-mode (850nm,0.1km,MPO,ISP) Price in Dubai UAE
Huawei QSFP-100G-SR4-ISP 100GBase-SR4 Optical Transceiver,QSFP28,100G,Multi-mode (850nm,0.1km,MPO,ISP) Price in Dubai UAE
Enquire on Whatsapp
Product Description
|
Specifications
|
||
|---|---|---|
| Model | QSFP-100G-SR4-ISP (Huawei Part No. 02312DXW) | |
| Product Type | Optical Transceiver | |
| Form Factor | QSFP28 (Quad Small Form-factor Pluggable 28) | |
| Data Rate | 100 Gbps | |
| Transmission Distance | Up to 100 meters | |
| Wavelength | 850 nm (Short Range) | |
| Fiber Type | Multi-mode Fiber (OM3/OM4) | |
| Connector Type | MPO/MTP-12 (12-fiber) | |
| Interface Standard | 100GBASE-SR4 (IEEE 802.3bm compliant) | |
| Transmitter Type | 4× VCSEL (Vertical Cavity Surface Emitting Laser) | |
| Receiver Type | 4× PIN Photodiode | |
| Digital Diagnostic Monitoring (DDM) | Supported (real-time monitoring of optical parameters) | |
| Power Consumption | ≤3.5 W (typical) | |
| Hot Swappable | Yes | |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) | |
| Compliance | RoHS Compliant, MSA Compliant, IEEE Standard Compatible | |
| Use Case | Short-distance 100G Ethernet over multi-mode fiber | |
