DME PROLINK D0713-C6ASRJ45 CAT6A Shielded RJ45 Field Terminable Plug (8-Pin) Price in Dubai UAE
DME PROLINK D0713-C6ASRJ45 CAT6A Shielded RJ45 Field Terminable Plug (8-Pin) Price in Dubai UAE
Enquire on Whatsapp
Product Description
|
Specifications
|
||
|---|---|---|
| Model / Part Number | D0713‑C6ASRJ45 | |
| Product Type | CAT6A Shielded RJ45 Field‑Terminable Plug | |
| Connector Format | 8P8C (8 positions, 8 contacts) | |
| Shielding | Fully shielded plug body (for shielded cable systems) | |
| Performance Category | Category 6A (meets ANSI/TIA‑568.2‑D CAT6A and ISO/IEC 11801 Class Ea requirements) | |
| Alien Crosstalk Suppression | Designed for enhanced alien‑crosstalk (AXT) performance | |
| Housing Material | Zinc alloy or equivalent shielded housing | |
| Contact Material | Phosphor bronze alloy contacts plated with gold | |
| Insulation / IDC Material | IDC termination designed for shielded cables | |
| Wire Gauge Compatibility | AWG 23 – AWG 26 | |
| Termination Method | Field‑terminable (no separate punch‑down tool required beyond plug assembly) | |
| Electrical Insulation Resistance | ≥ 500 MΩ @ 100 VDC | |
| Dielectric Withstanding Voltage | 1,000 V (contact to contact) | |
| Suitable Applications | High‑density data centres, 10 Gbps Ethernet, shielded cable infrastructures | |
| Typical Use Case | Field termination of shielded CAT6A cable to RJ45 plug in the field | |
