APC E3SOPT032 Easy UPS 3S IP40 Kit 30–40 kVA, 400V 3:1 & 3:3 UPS | For Internal Batteries Price in Dubai UAE
APC E3SOPT032 Easy UPS 3S IP40 Kit 30–40 kVA, 400V 3:1 & 3:3 UPS | For Internal Batteries Price in Dubai UAE
Enquire on Whatsapp
Product Description
|
Specifications
|
||
|---|---|---|
| Product Name | APC E3SOPT032 Easy UPS 3S IP40 Kit | |
| Compatible UPS Ratings | 30 kVA & 40 kVA, 400 V 3:1 & 3:3 UPS with internal batteries | |
| Protection Class | IP40 with kit installed | |
| Application / Use | Indoor UPS installations with internal batteries | |
| Load Derating | UPS may require load/overload derating when IP40 kit installed | |
| Topology | Double-conversion online | |
| Input Voltage Range | 304–477 V 3-phase | |
| Input Frequency Range | 45–65 Hz | |
| Input Power Factor | >0.99 | |
| Output Voltages (3:1 / 3:3) | 220–240 V / 380–415 V | |
| Output Power | 30–40 kVA / 30–40 kW | |
| Output Voltage Tolerance | ±1 % | |
| Overload Capacity | 130 % for 10 min; 130–150 % for 1 min | |
| Efficiency (Double Conversion) | Up to ~96 % | |
| ECO Mode Efficiency | Up to ~99 % | |
| Battery Type | VRLA (internal batteries) | |
| Nominal DC Bus Voltage | ±192–±240 V | |
| Charging Power | Programmable 1–20 % | |
| Operating Temperature | 0 °C – 40 °C | |
| Operating Humidity | 0–95 % non-condensing | |
| Operating Elevation | 0–1000 m | |
| Noise Level | ~63 dBA | |
| Communication & Control | RS485, Dry contacts, Ethernet (SNMP/Modbus/BACnet) | |
| Dimensions (HxWxD mm) | ~1400 × 500 × 969 | |
| Weight | ~152–195 kg | |
| Notes | IP40 kit is a mechanical/environmental upgrade; core UPS specs follow the underlying UPS ratings | |
