Product Description
|
Specifications
|
||
|---|---|---|
| Model | APC BR1200G-FR | |
| Product Line | Power-Saving Back-UPS RS | |
| UPS Type | Line-Interactive UPS | |
| Power Capacity | 1200 VA / 720 W | |
| Nominal Input Voltage | 230 V AC | |
| Input Frequency | 50/60 Hz | |
| Waveform Type | Stepped approximation to sine wave | |
| Nominal Output Voltage | 230 V AC | |
| Total Outlets | 6 × CEE 7/5 (Type E/F) | |
| Battery Type | Sealed lead-acid (VRLA) | |
| Battery Recharge Time | ~8 hours | |
| Replacement Battery Cartridge | APCRBC124 | |
| USB Port | 1 USB 2.0 port for monitoring | |
| Modem/Phone Protection | 1 × RJ-11 | |
| Ethernet LAN Protection | 1 × RJ-45 | |
| Surge Energy Rating | ~445 J | |
| Transfer Time (Utility → Battery) | ~10–12 ms | |
| Audible Alarms | Yes | |
| Noise Level | ~45 dB | |
| Cable Length | ~1.83 m | |
| Dimensions (H × W × D) | 301 × 112 × 380 mm | |
| Weight | ~11.6 kg | |
| Operating Temperature | 0–40 °C | |
| Operating Humidity | 0–95 % non-condensing | |
| Form Factor | Tower | |
| Color | Black | |
