Product Description
|
Specifications
|
||
|---|---|---|
| Product Model | AP8888 | |
| Product Type | Metered Rack PDU (2G) | |
| Form Factor | Zero U (vertical rack mount) | |
| Input Voltage | 240 V AC | |
| Input Current Rating | 32 A (typical for this power level) | |
| Power Capacity | Approx. 23.0 kW | |
| Input Connector | IEC 60309 32 A 2P+E plug | |
| Input Frequency | 50/60 Hz | |
| Output Receptacles – C13 | 30 × IEC 60320 C13 | |
| Output Receptacles – C19 | 12 × IEC 60320 C19 | |
| Cord Length | ~3 m (approx.) | |
| Metering & Monitoring | Local digital metering (volts, amps, power, energy) with network monitoring support | |
| Network Management | Compatible with remote monitoring (Web, SNMP, Telnet) | |
| Overload Protection | Built‑in circuit protection and alerts | |
| Mounting Orientation | Vertical rack mount (Zero U) | |
| Operating Temperature | −5 °C to 60 °C | |
| Operating Humidity | 5–95 % RH (non‑condensing) | |
| Dimensions (H × W × D) | Approx. 1791 × 56 × 44 mm | |
| Net Weight | Approx. 9.0 kg | |
| Color | Black | |
| Certifications / Compliance | UL/CSA/IEC safety standards; RoHS & REACH compliant | |
