Alcatel-Lucent OS6360-P10 OmniSwitch 10-Port 1RU Fanless PoE Gigabit Switch Price in Dubai UAE
Alcatel-Lucent OS6360-P10 OmniSwitch 10-Port 1RU Fanless PoE Gigabit Switch Price in Dubai UAE
Enquire on Whatsapp
Product Description
|
Specifications
|
||
|---|---|---|
| Product Name | Alcatel-Lucent OmniSwitch 6360-P10 | |
| Switch Type | Managed, stackable, Layer-3 capable Gigabit Ethernet switch | |
| Form Factor | 1U rack-mountable (½-rack width) / fanless design | |
| Ports / Interfaces | 8 × 10/100/1000 RJ-45 PoE+ ports + 2 × 10/100/1000 RJ-45 uplink ports + 2 × 1G SFP uplink ports; console port; USB / out-of-band management port | |
| PoE / Power Budget | PoE+ support; total PoE budget up to ~120 W | |
| Switching / Forwarding Capacity | ASIC switching capacity ~40 Gbps; full-duplex switching ~24 Gbps; frame forwarding rate ~35.7 Mpps; latency < 4 µs | |
| VLAN / MAC / Frame Support | Up to ~4000 VLANs; MAC address table size ~16,000 entries; supports jumbo frames (~9216 bytes) | |
| Stacking / Virtual Chassis | Supports stacking up to 4 units (virtual chassis) | |
| Management / Protocols | SNMP (v1‐3), RMON; HTTP/HTTPS; Telnet; SSH; CLI; DHCP client/relay; NTP; IPv4 & IPv6; ACLs; LLDP; LLDP-MED; 802.1X authentication; QoS; flow control; VLAN tagging; Spanning Tree (STP, RSTP, MSTP); IGMP/MLD snooping; static routing (IPv4 & IPv6) | |
| Memory / CPU / Storage | CPU: 800 MHz ARM; RAM: ~1 GB; Flash memory: ~1 GB; Packet buffer: ~1.5 MB | |
| Power / Electrical | Internal power supply; power consumption (with full PoE load) ~145 W; standby / idle ~11 W without PoE load | |
| Physical & Environmental | Dimensions ~21.7 cm W × 28 cm D × 4.4 cm H; weight ~2.1 kg; operating temp 0 °C to 45 °C; storage temp -40 °C to 85 °C; humidity 5-95% non-condensing | |
| Acoustics / Cooling | Fanless operation (silent) in all modes; no active cooling fans | |
| Reliability / MTBF | Mean time between failures ~1,094,000 hours | |
