APC APTF10KW01 WW 10KVA Isolation Transformer – High Efficiency Power Protection Price in Dubai UAE
Enquire on Whatsapp
Product Description
|
Specifications
|
||
|---|---|---|
| Model | APTF10KW01 | |
| Product Type | Isolation / Step‑Down Transformer | |
| Power Capacity | 10 kVA / 10,000 VA | |
| Nominal Input Voltage | 208 V / 230 V / 240 V AC | |
| Nominal Output Voltage | 120 V / 208 V / 230 V / 240 V AC | |
| Input Frequency | 45 – 65 Hz | |
| Input Connection Type | Hard wire 3‑wire (1P + N + E) and Hard wire 3‑wire (2P + E) | |
| Output Connection Type | Hard wire 3‑wire (H N + E) | |
| Maximum Input Current | 60 A | |
| Maximum Line Current | 60 A | |
| Efficiency (Full Load) | ~95 % | |
| Mounting Type | Rack‑mountable (4U) | |
| Form Factor | 4U Rack Height | |
| Dimensions (Approx.) | 175 mm (H) × 432 mm (W) × 749 mm (D) | |
| Net Weight | ~100 kg | |
| Color | Black | |
| Operating Temp. Range | 0 °C to 40 °C | |
| Operating Humidity | 0 – 95 % RH | |
| Operating Altitude | 0 – 3048 m | |
| Storage Temp. | −25 °C to 65 °C | |
| Storage Humidity | 0 – 95 % RH | |
| Certifications / Approvals | CSA, EN 55022, EN 55024, EN 61000‑3‑2/‑3, UL Listed | |
| Typical Use | Power isolation, step‑down/‑up conversion, UPS support | |
